YOKOGAWA PW482-S01?
YOKOGAWA PW482-S01
YOKOGAWA PW482-S01

Terminal Type Multiplexer Module
The terminal type multiplexer module is installed in the Nest for Terminal-type I/O Modules
(AMN31). Up to two modules can be installed in one nest. Signal cables are connected by M4
screws to the terminals of the module. Two or three signal cables are connected for each I/O
channel.
Connector Type Multiplexer Module
The connector type multiplexer module is installed in the Nest for Connector-type I/O Modules
(AMN32). Up to four modules can be installed in one nest. Using a KS2 cable (or a KU2 cable),
connect it to Signal Conditioner Nest, MUB/MUD Terminal Board or TE16/TE32 Terminal Block.
Connect signal wiring from the field to the terminals of the terminal board or the terminal block
with M4 screws.
Relay I/O Module
The relay I/O module is installed in the Nest for Relay I/O Modules (AMN21). Only one module
is installable in one nest. Signal cables are connected to the terminals of the module with M4
screws. Two or three signal cables are connected for each I/O channel.

YOKOGAWA PW482-S01
YOKOGAWA PW482-S01
YOKOGAWA PW482-S01

V net
V net is a 10 Mbps real-time control bus which links stations such as FCS, HIS, BCV and CGW. It
can be dual redundant. There are two types of cable
• YCB111 cable Connects station other than HIS and FFCS (e.g. FCS other than FFCS,
CGW). Length up to 500 m.
• YCB141 cable Connects HIS and FFCS. Length up to 185 m.
YCB111 cable and YCB141 cable can be connected by cable converter unit or bus repeater.
When these cable types are combined, maximum length is computed as follows
YCB141 cable length + YCB111 cable length x 0.4 ? 185 m
For example, if YCB141 = 5 m and YCB111 = 450 m, then the above equation becomes
Effective length
= 5 m (YCB141 cable length) + 450 m (YCB111 cable length) x 0.4
= 5 m + 180 m
= 185 m
So the condition that the total length of YCB141 should not exceed 185 m is satisfied.
Extending the V net
When the V net is extended, Field Control Stations distributed around a large plant can be
monitored from HIS in a central control room. Bus repeaters and optical repeater pairs can be
mixed, up to four sets in total, to extend the V net up to 20 km.
